Dimensions and properties
|
Physical |
fiber type |
ITU-T G.657A2 |
||
|
fiber count |
4 |
8 |
12 |
|
|
No. of fiber per loose tube |
4 |
8 |
12 |
|
|
Cable dimension (H*W) – mm ± 0.1mm |
3.5*7.4 |
|||
|
Cable weight kg/km ± 15% |
30 |
|||
|
Operating temperature range |
-40°C to +70°C |
|||
|
Installation temperature range |
-30°C to +60°C |
|||
|
Properties |
Transport and storage temperature range. |
-40°C to +70°C |
||
|
Max. tensile load (MAT) – N |
1300 |
|||
|
Crush resistance – N/10cm |
2200 |
|||
|
Minimum installation bending radius |
20*H |
|||
|
Minimum operating radius of curvature |
10*H |
|||
